Mix Heads

VSE flow measurement equipment is used worldwide in technical process plant in the plastics, chemical, pharmaceutical, paints, and inks, hydraulic and automotive industries, as well as for 2K technology.

Request a Quote

Call for a Quote: 616.394.0191

  • Description
  • Used Mix Heads

Product Description

MHR’s Tri-Tilt Mix Head provides an improved chemical mixing action for the Polyurethane/Foam industry. Development of the Tri-Tilt Mix Head was done utilizing Computational Fluid Dynamics Technology. The computerized simulation of material flow through the orifices at high pressure and various tilted positions has allowed MHR’s Tri-Tilt Mix Head to achieve nearly perfect mix in the mix chamber and as the material flows from nose nozzle into the mold. It was determined that these superior mix results could be accomplished through non-linear and non-coplanar impingement
occurring along 3 independent axises.

The net result for the molding operation that uses MHR’s Tri-Tilt Impingement Mix Heads is a highly improved, consistent, well-mixed laminar flow output with a consistent cellular structure throughout the finished product.

MHR’s customers find significant improvement in their difficult-to-mold parts; we expect the same for your operation.

Mix Head Features:

  • Triple shaft seal and scraper bushing on clean-out rod
  • Long-wearing clean-out and pour rods
  • Adjustable clean-out stroke for better mix control
  • PFTE, VITON and other seal materials compatible with MPI, TDI, and corrosive
    blowing agents
  • 2 proximity switches – PNP 3-wired D.C. current, normally open
  • Orifice sizes: 0.5MM through 4.2 MM. Your specific sizes supplied with mix head
  • Chemical and hydraulic ports: SAE straight thread ‘O’ ring fittings with JCI 37°
    flared ends. Your specific sizes supplied with mix head
  • Clean-out hydraulics separated from chemicals with one piece cylinder extension
    with windows
  • Third stream color port (optional) for dosing system or recirculation system
  • MHR TRI Mix Heads can be customized to meet your requirements including custom
    seals
Mix Head Sizing Chart
MINIMUM THROUGH PUT MAXIMUM THROUGH PUT
MODEL SIZE/INCHES WT. (LBS) OPEN & CLOSED MOLD OPEN MOLD LAMINAR FLOW CLOSED MOLD
A (Height) B (Width) C (Length) 1:1 RATIO 2:1 RATIO 1:1 RATIO 2:1 RATIO 1:1 RATIO 2:1 RATIO ADJ. STOKE MAX % CLOSE OFF
MHR TT 8/12 6.13 5.62 14.88 19 60 g/s 90 g/s 340 g/s 255 g/s 420 g/s 315 g/s 60%
MHR TT 10/14 6.91 7.48 16.85 35 100 g/s 135 g/s 460 g/s 345 g/s 1000 g/s 750 g/s 60%
MHR TT 12/18 7.29 7.71 19.03 44 160 g/s 240 g/s 760 g/s 570 g/s 2000 g/s 1500 g/s 60%

This is a used 8/12 Impingement Mix Head. Call for a Quote.
